Metro Range
Metro range of wood plastic timber decking is a circular hollow board. They are lightweight and easy to handle, making them perfect for most residential new decking projects. Suited to subframes with joist spacings up to 350mm.
Product
Profile | Profile Code | Description | Dimensions | Length | Finish | Double Sided | LM p/m2 | Residential Span | Commercial Span | Secret Fix | Weight p/LM | Slip Rating |
UH02 | Grooved Edge Hollow Decking board | 138mm x 23mm | 4.88m | H6 / H1 | Y | 7m | 350mm | N/A | Y | 2.65kg | P2 | |
US07 | Square Edge Solid finishing board | 138mm x 23mm | 4.88m | H6 / H1 | Y | 7m | 400mm | 300mm | N | 3.5kg | P2 | |
US06 | Solid Fascia board | 138mm x 15mm | 4.88m | H6 / H1 | Y | 7m | 800mm | N/A | N | 2.42kg | N/A |
Profile | Profile Code | Description | Gap | Timber Fix | Metal Fix | Clips P/M2 Terrace Range | Clips P/M2 Coastal Range | Clips P/M2 Metro Range |
COBRA T-CLIP | Cobra T-Clip | 5.5mm | Y | Y * Δ | 17 | 14 | 21 | |
MG1 | Mini Gap Clip | 1.5mm | Y | Y Δ | 19 | 15 | 22 | |
MG2 | Mini Gap Locking Clip | 1.5mm | Y | Y Δ | 1 Clip / Length | 1 Clip / Length | 1 Clip / Length | |
MG3 | Starter Clip | n/a | Y | N | n/a | n/a | n/a | |
K37 | Starter / End Clip | n/a | Y | Y Δ | n/a | n/a | n/a | |
CS | Coloured Head Fascia Screw – 304ss – 8g x 50mm | n/a | Y | N | n/a | n/a | n/a | |
CDS | DeckHedz Coloured Head Decking Screw – 304ss – 10g x 65mm | n/a | Y | N | n/a | n/a | n/a | |
CSM | Coloured Head Decking Screw – Carbon Steel – 10g x 60mm | n/a | Y | Y Δ | n/a | n/a | n/a | |
EC-UH02 / EC-UH17 / EC-UH25 / EC UH55 | End Caps suitable for hollow profiles | n/a | n/a | n/a | n/a | n/a | n./a |
Terrence Range
Stylish, contemporary Terrace Range solid composite timber decking is suited to both residential and commercial projects. This eco friendly and natural looking composite deck boards are suited to subframes with joist spacings up to 450mm.
Profile | Profile Code | Description | Dimensions | Length | Finish | Double Sided | LM p/m2 | Residential Span | Commercial Span | Secret Fix | Weight p/LM | Slip Rating |
US49 | Grooved Edge Solid Deck board | 138mm x 25mm | 5.4m | H11 / H6 | Y | 7m | 450mm | 350mm | Y | 3.85kg | P2 | |
US63 | Grooved Edge / Solid Edge Solid Deck board | 138mm x 25mm | 5.4m | H11 / H6 | Y | 7m | 450mm | 350mm | Y | 3.89kg | P2 | |
US06 | Solid Fascia board | 138mm x 15mm | 4.88m | H6 / H1 | Y | 7m | 800mm | N/A | N | 2.42kg | N/A |
FAQ – NewTechWood Composite Decking Supply and Installation in Perth
Q. What makes NewTechWood extra special compared to other decking products?
Compared to regular timber decking products, NewTechWood features high UV-resistant properties which safeguard against the burning sun and protects the quality of the decks including their texture and colour. Aside from that, NewTechWood is also made from 95% recyclable materials.
Q. What’s the difference between the Metro Range and the Terrace Range?
NewTechWood’s Metro Range is exclusive to Western Australia. This collection features natural-looking, lightweight decking made from circular and hollow planks. Terrace Range, on the other hand, is made from solid composite timber decking that’s perfect for areas with heavy foot traffic.
Q. What panel sizes are available?
The Metro Range is available in 138mm x 15mm and 23mm (dimension) with a 4.88m length – perfect for residential installations. While the Terrance Range is 138mm x 15mm and 23mm (dimension) with a 4.88m and 5.4m length and is fit for commercial installations.
Q. Is there a variety of colours to choose from?
We stock from NewTechWood’s Metro Range (only available in WA) as well as their Terrance Range. The collection consists of 26 colours classified under Decking Terrace, Decking Coastal, Decking Metro, Wall Cladding, Castellation Cladding and Screening. Please get in touch with us to schedule a visit to our Perth showroom to browse these products.
Q. Is there a special cleaning technique or product required for composite decking?
Aside from regular sweeping and damp mopping, NewTechWood Timber Decking requires no oiling, sanding or painting to freshen the decks.
Q. What else can I use NewTechWood decking as?
Aside from the usual flooring, decking boards can also be used as exterior wall cladding or as a feature wall to your interior space. The boards can also be used as fencing as well as materials for DIY building projects such as an outdoor bar or a play area.
Q. How much will it cost to install NewTechWood Timber Decking?
To request a free quote, please get in touch with us or speak to our flooring specialists on (08) 9331 5004.
Q. Is there a warranty available for this product?
There is a 25-Year Guarantee for residential flooring and decking installations for NewTechWood products. Speak with our customer service on (08) 9331 5004 to check product availability today.
